Those that exceed the length are called “over-extension” slides because they travel over 100% and up to 180% of the length of the drawer slide assembly.įull-extension drawer runners, are useful if you need easy access to contents, as with kitchen utensil drawers, and point of sale trays.
#Slide runner indoor slide full
In combination, these members tend to extend either the full (100%) length of the drawer slide assembly or even beyond that. Three or four profile drawer slides have two or three moving components, the drawer, and intermediate members.
This drawer slide is perfect for small retail displays. One of our single extension drawer runners is the Junior 1710.
We also call these drawer runners “single extension”. That means the moving drawer profile travels at 75%, of the slide’s length. A simple drawer runner that uses just two members, an inner and an outer, generally provides a 75% extension. How far a drawer runner extends or moves, is called extension or travel. The length refers to the total length of the slide assembly when collapsed in the closed position. We have stock items available as little as 18 cm to as long as 150 cm. Thomas Regout International drawer runners come in many lengths. To mount the drawer to the cabinet/ application we can incorporate several fixations into the design of the slide: holes, countersunk holes, press inserts, studs, studs threaded, tabs/ bayonets, slotted strip bracket, spacer bracket, or a drawer carrier. Undermount drawer runners are often used in high-end kitchen cabinets as they do not interfere with the look of the cabinet design. An undermount drawer runner is often used where it’s desirable to conceal the drawer slide components from view or allow the drawer to be slightly wider. Side mount drawer runners are easy to install, provide good visibility of the drawer contents, and are ideal for use in…Īn undermount drawer runner, such as the ADO TR-4522mounts in a position that allows a specially designed drawer to sit on top of the suspension, unlike a side mount drawer runner. Most Thomas Regout International drawer runners are side-mounted, meaning they’re mounted on the side of the drawer and within the cabinet structure. Drawer runners can also be classified on how they mount.Īdditionally, drawer runners can come in two arrangements: side mount and under mount. To assist you in the process of choosing the right drawer runner, we incorporated a useful tool on our website: the product selector. The TR – 7619 Jumbo is an example of a heavy-duty slide, which has a load rating of up to 310 kg. Heavy-duty applications include pull-out trays on an emergency or recreational vehicles, ATMs, and utility/service trucks. Heavy-Duty Drawer Runners - Load capacities for some of TRI’s heavy-duty drawer runners can reach up to 2000 kg.Medium Duty Drawer Runners - Support between 51 to 99 kg and are used in draws that contain heavier items such as pots and pans.Light Duty Drawer Runners - Support up to 78 kg in weight and are used in domestic applications such as drawers in kitchen furniture.Thomas Regout International drawer slides’ load capacities fall into three ranges:
Determining how much load-capacity you need is key in choosing the right slide. The load capacity and the type of application determine in which classification of our product program you can find a suitable drawer runner. Only the drawer and intermediate profiles move while the cabinet member remains fixed to its location within the cabinet structure. (or two) profile(s) located between the cabinet and drawer profiles. Only one of the slide members ( drawer) moves when opening a drawer.Ī more complex drawer runner structure will include three or four profiles, with an intermediate The bearings, secured within metal ball retainers, fit between the profiles, and ensure that movement is smooth and noiseless.Ī simple drawer runner has two profiles: a drawer ( inner) profile that attaches to the side of a drawer box, and a cabinet ( outer) profile that attaches to the cabinet’s or application’s inner wall surface, within the drawer opening. These slides feature lubricated bearings that move drawers and a linear direction, allowing smooth opening and closing action. Ball bearing drawer runners are also known as rails, runners, and sliders. Thomas Regout International manufactures high-quality ball bearing drawer runners, all produced in our production plant in The Netherlands.
#Slide runner indoor slide how to
Here’s a brief guide to help you understand the basics of a drawer runner and how to choose the right one for your application. What goes into a good drawer runner and how do you examine the right one for your need? What is a Drawer Runner and how Do I choose the right one?Ī good and convenient drawer runner can save you a lot of irritation.
